Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Switching Diode
Maximum Forward Current If
2A
Diode Configuration
Common Cathode
Sub Type
Silicon Junction
Mount Type
Through Hole
Package Type
TO-220
Pin Count
3
Maximum Forward Voltage Vf
1.05V
Minimum Operating Temperature
-65°C
Peak Non-Repetitive Forward Surge Current Ifsm
120A
Peak Reverse Recovery Time trr
35ns
Maximum Peak Reverse Repetitive Voltage Vrrm
600V
Maximum Operating Temperature
175°C
Height
16.4mm
Length
10.4mm
Standards/Approvals
No
Automotive Standard
No
Country of Origin
China
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
€ 41.28
€ 1.651 Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
25
€ 41.28
€ 1.651 Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
25
| Quantity | Unit price | Per Tube |
|---|---|---|
| 25 - 45 | € 1.651 | € 8.26 |
| 50 - 120 | € 1.49 | € 7.45 |
| 125 - 245 | € 1.34 | € 6.70 |
| 250+ | € 1.271 | € 6.35 |
