Omron PCB Mount Power Relay, 12V dc Coil, 8A Switching Current, SPDT
Technical Document
Specifications
Brand
OmronCoil Voltage
12V dc
Contact Configuration
SPDT
Mounting Type
PCB Mount
Switching Current
8A
Number of Poles
1
Latching
No
Terminal Type
Through Hole
Length
28.8mm
Coil Resistance
655Ω
Height
15.3mm
Series
G6RN
Depth
10.5mm
Contact Material
Gold Plated
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+85°C
Maximum Switching Power DC
150 W
Maximum Switching Power AC
2 kVA
Application
Power
Country of Origin
Malaysia
Product details
G6RN Series
Fully sealed
8mm creepage and clearance
Minimum contact load: 100mA @ 5mVdc
Switching Voltage: 250 Vac
Contact Resistance: 50mΩ
Mechanical Life: 10 x 106
Contact Material: AgNi
Operating Temperature: -40 → +85°C
H15, W28.5, D10mm
Approvals
VDE
Standards
IEC,CENELEC
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
Please check again later.
€ 7.02
Each (ex VAT)
1
€ 7.02
Each (ex VAT)
1
Buy in bulk
| quantity | Unit price |
|---|---|
| 1 - 24 | € 7.02 |
| 25 - 49 | € 5.96 |
| 50 - 99 | € 5.62 |
| 100 - 249 | € 5.26 |
| 250+ | € 4.95 |
