Texas Instruments CD4013BE Dual D Type Flip Flop IC, 14-Pin PDIP
Technical Document
Specifications
Brand
Texas InstrumentsLogic Family
4000
Logic Function
D Type
Input Type
Single Ended
Output Signal Type
Differential
Triggering Type
Positive Edge
Polarity
Inverting, Non-Inverting
Mounting Type
Through Hole
Package Type
PDIP
Pin Count
14
Set/Reset
Yes
Number of Elements per Chip
2
Maximum Propagation Delay Time @ Maximum CL
300 ns @ 5 V
Dimensions
19.3 x 6.35 x 4.57mm
Maximum Operating Supply Voltage
18 V
Minimum Operating Temperature
-55 °C
Height
4.57mm
Propagation Delay Test Condition
50pF
Maximum Operating Temperature
+125 °C
Length
19.3mm
Width
6.35mm
Minimum Operating Supply Voltage
3 V
Product details
4000 Series Flip-Flops & Latches, Texas Instruments
Texas Instruments range of Flip-Flops and Latches from the 4000 Series CMOS Logic Family
4000 CMOS Logic Family, Texas Instruments
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
Please check again later.
€ 0.591
Each (In a Pack of 20) (ex VAT)
Standard
20
€ 0.591
Each (In a Pack of 20) (ex VAT)
Standard
20
Buy in bulk
| quantity | Unit price | Per Pack |
|---|---|---|
| 20 - 80 | € 0.591 | € 11.83 |
| 100 - 180 | € 0.562 | € 11.23 |
| 200 - 480 | € 0.505 | € 10.11 |
| 500 - 980 | € 0.455 | € 9.11 |
| 1000+ | € 0.433 | € 8.66 |
