TE Connectivity Panel Mount Power Relay, 12V dc Coil, 20A Switching Current, DPDT
Technical Document
Specifications
Brand
TE ConnectivityCoil Voltage
12V dc
Contact Configuration
DPDT
Mounting Type
Panel Mount
Switching Current
20A
Number of Poles
2
Latching
No
Terminal Type
Quick Connect
Length
73.66mm
Coil Resistance
120Ω
Height
38.9mm
Contact Material
Silver Alloy
Minimum Operating Temperature
-45°C
Series
KUHP
Maximum Operating Temperature
+70°C
Depth
35.7mm
Application
Power
Product details
KUHP Series Relay
The KUHP series are enclosed 30A switching capability power relays.
.250" combination push-on/solder terminals
Slotted flanges for bracket mounting to a chassis
Designed to meet VDE space requirements
Class B coil insulation
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 27.56
€ 27.56 Each (ex VAT)
1
€ 27.56
€ 27.56 Each (ex VAT)
1
Stock information temporarily unavailable.
Please check again later.
| quantity | Unit price |
|---|---|
| 1 - 4 | € 27.56 |
| 5 - 9 | € 26.77 |
| 10+ | € 25.58 |
