EPCOS, B84142-A 30A 250 V ac/dc 60Hz, Flange Mount EMC Filter, Screw, Single Phase
Technical Document
Specifications
Brand
EpcosMaximum Current Rating
30A
Maximum Voltage Rating
250 V ac/dc
Mounting Type
Flange Mount
Termination Style
Screw
Number of Phases
1
Number of Stages
Two Stage
Series
B84142-A
Operating Frequency
60Hz
Length
105mm
Depth
130mm
Height
68mm
Dimensions
105 x 130 x 68mm
Leakage Current
7.9 mA
Resistance
5mΩ
Standards Met
UL 1283
Product details
B84142-Ax-R Series
This series is a new development, that features a highly compact construction.
Two-line filter for electrical systems in lifts, conveyor belts, pumps, ventilation systems and power supply units
Very high insertion loss
Optimized for very long motor cables under full load
Low leakage current
Protection type IP20
Approvals
UL1283 CSA22.2 No. 8 (construction)
€ 82.59
€ 82.59 Each (ex VAT)
1
€ 82.59
€ 82.59 Each (ex VAT)
1
Stock information temporarily unavailable.
Please check again later.
| quantity | Unit price |
|---|---|
| 1 - 4 | € 82.59 |
| 5 - 9 | € 80.42 |
| 10 - 24 | € 78.36 |
| 25+ | € 76.40 |
